78mm 1/2" Ceramic Disc Cartridge - Anti-Clockwise Open - 45Z-7S8

SUMMARY

78mm 1/2 Inch Ceramic Disc Cartridge - Anti-Clockwise Open - 45Z-7S8

Cartridge Measurements:
Total Length (including bottom seal): 78mm
Spindle Length: Diameter at Widest Point: 23.7mm
Top Spline Diameter: 7.6mm
Top Spline Teeth / Notches: 20
Lower Thread Diameter: 20.6mm
Barrel Diameter Below Lower Thread: 18.3mm
Bottom Seal Colour: Blue
Close Direction: Anti-Clockwise Close (Clockwise Open)
Turn: Quarter Turn (1/4 Turn) 90°
Upper Thread (closer to spline): 23.7mm


– Other Flow Cartridges


The plumbing grease can be found in the "Related Items" below.
