D1-05 Shower Trap (Steam Outlet)
D1-05 Shower Trap (Steam Outlet)D1-05 Shower Trap (Profile)D1-05 Shower Trap (Rear)D1-05 Shower Trap (Rear Underside)D1-05 Shower Trap (40mm)D1-05 Shower Trap (Part Breakdown)

Plastic Shower Waste Drain Trap with Chrome Cover with Steam Pipe Spigot - 85mm

Part Number: 06050099
Out of stock - Ask a Question now
Price: £29.95
Price includes VAT
Stock Arrival Notification
-- or --
Request Stock Date
Wrong Item? Click to see More
Product description


This is an anti-smell drain specifically designed for steam shower rooms. There is a pipe node on the drain which connects a pipe from the drain to the overflow on the steam generator. This overflow however could be used for something else if it isn't used for the steam overflow.

Fitting & Further Information

The mounting hole required is 85mm - Please ensure that the shower tray or fitting hole meets this requirement. The fitting thread is 30mm deep. The drain housing is 85mm tall.

Underneath the chrome plated plastic top there is a basket which catches the majority of hair and other materials which are washed into the drain, which will limit the risk of the pipes becoming clogged.

The exit is for 40mm 1 1/2" inch waste pipes.

This drain is used on several TC Traditional Contemporary steam showers.
