Steam Shower 3-way Diverter Cartridge for A-323, A-286, SS-A-323, A323
SUMMARY
This spare part is a 3-way diverter cartridge used in multi-function steam shower valve assemblies A-323, A-286, SS-A-323 and A323.
It directs water between three outlets, such as the overhead shower, hand shower, and body jets, and restores proper outlet selection when the original diverter is stiff, leaking internally, or no longer switching cleanly between functions.
Technical Details
- - Type: 3-way diverter cartridge for steam shower valve assemblies
- - Barrel dimensions for this cartridge: approximately 34 mm in diameter and 29 mm in height
- - Spindle diameter: 10 mm
- - Brass spindle length: 55mm
- - Overall length: 90 mm
- - Before ordering check: compare the overall length, exposed spindle length, barrel diameter, barrel height, and spline form with your original cartridge because visually similar steam shower diverters are not all the same
Installation Notes
- - Isolate the water supply before removing the old diverter cartridge
- - Light lubrication of the seals can help to protect the O-rings during installation
Common Signs of Failure
- - Water continues to feed the wrong outlet or more than one outlet at the same time
- - The selector becomes stiff, loose, or fails to index cleanly between shower functions
Related Spares You May Need
- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
