Dornbracht 909003160090 Diverter Cartridge - Non-Shut Off

SUMMARY

Dornbracht 909003160090 is a non-shut-off diverter cartridge for shower valves where the cartridge is used to divert water between outlet functions.

This cartridge does not stop the flow of water. It is designed for function selection only, so if water continues to pass when the shower or tap is turned off, the shut-off or flow control component should also be checked before ordering.

Technical Details

- - Total length excluding white spline adapter: 99mm

- - Spindle length: 62mm

- - Barrel diameter: 27mm

- - Function: diverts between water outlet functions

- - Shut-off function: no

Pre-Order Check

Check the full cartridge length, spindle length, barrel diameter and spline arrangement against the removed cartridge before purchase. Do not order this cartridge for a valve fault where the part required must independently stop water flow.

Installation Note

When fitting the cartridge, inspect the internal valve body and seals. Apply a suitable silicone grease to the O-rings and bottom seals to help the cartridge seat correctly and reduce seal drag during operation.

Troubleshooting

- - Symptom: water changes outlet poorly or does not divert correctly

- - Likely Cause: worn or sticking diverter cartridge

- - Solution: replace the diverter cartridge after checking the valve body and handle connection

- - Symptom: water continues to flow when the valve is turned off

- - Likely Cause: this non-shut-off diverter cartridge is not the component that stops water flow

- - Solution: check the valve shut-off or flow control part before ordering

Related Spares You May Need

- - TACSIL 3g Premium Cartridge Silicone Grease - WRAS Approved
