Dornbracht 9090031600090 Lifetime Diverter Cartridge - 100mm Length (27mm Diameter)
Send a photo of your item and we'll help confirm it.
Summary
Dornbracht 9090031600090 Lifetime diverter cartridge for Dornbracht xGate / Symetrics xGate mixer valve applications. This cartridge is used to divert water between outlets and does not shut the water off.
The same manufacturer code may also be shown as 90 90 03 160 00 90 and is described in spares data as a Lifetime Mix 90 degree temperature-control upper part for xGate applications.
Technical Details
| Manufacturer code | 9090031600090 |
|---|---|
| Alternate spaced code | 90 90 03 160 00 90 |
| Di Vapor Part Number | D-9090031600090 |
| Part type | diverter cartridge / Lifetime Mix 90 degree upper part |
| Function | diverts water between outlets only |
| Total length | 100mm |
| Diameter at bottom | 27mm |
| Catalogue diameter note | 29mm at another measured point |
Confirmed Compatible Models
- Dornbracht xGate / Symetrics xGate mixer valve with volume regulation for deck mounting 20 020 980/985 - FF
Pre-Order Check
Check the cartridge length, bottom diameter, valve model and existing cartridge code before ordering. If the fault is water continuing to run when the shower or tap is turned off, this diverter cartridge may not be the shut-off part and the flow-control or stop cartridge should also be checked.
