101mm 3-Way Shower Diverter Cartridge - 24 Splines

SUMMARY

101mm 3-Way Shower Diverter Cartridge - 24 Splines

Brief Technical Overview
- Total Length: 101mm (10cm)
- Barrel Width: 33mm at plastic and 34mm at O-ring
- Spline Length (Including Toothed Spindle): 64mm (6.4cm) (may be 6.3cm or 63mm and up to 65mm / 6.5cm)
- Number of Teeth on Handle Spindle: 24 (9.6mm diameter)
- Distance Between Locating Pins: 19.7mm from locating pin centre to centre


Frequently Asked Questions: 3-Way Shower Diverter Cartridge

Question: How can I count the diverter cartridge splines?
Answer: Splines can be manually counted with ease. All that’s needed to be done is to mark the beginning point with a pen and count the notches from there. This green diverter valve part has 24 splines, thus, the old cartridge should also have 24. This will guarantee that this spare part will fit in your shower valve.

Question: The cartridge diverter part has a different colour than this. Is this the right spare?
Answer: You can check the measurements of the 3-way shower diverter given above.

If you need any help:
– Please send us a photo of the cartridge in question. We will tell you which is the right spare part for it.
– Or, you can opt to talk to one of our spares experts via 08454 650 800.


We offer many shower diverter valve spare parts. You can browse through our extensive catalogue. There is a big possibility we have exactly what you need.
