Bristan SK760101 Spare Green 7L/​m Flow Limiter

SUMMARY

Bristan SK760101 is the green 7 L/min flow limiter used in Bristan mini valve thermostatic mixer showers. It fits within the inlet assembly and helps set the correct flow rate for the valve arrangement.

In Bristan service information for this shower family the green regulator is the 7 litre version, while the yellow regulator is the 5 litre version. The regulator is factory fitted in the valve assembly and is removed from the inlet elbow and non-return valve retainer during servicing.

Technical Details

- - Part Number: SK760101

- - Part type: flow limiter / flow regulator

- - Colour identifier: green

- - Rated flow: 7 L/min

- - Position: fitted within the inlet assembly and non-return valve retainer arrangement

- - Shower family details: the documented exposed mini valve family uses 15 mm compression inlets with adjustable centres from 110 mm to 155 mm

Before ordering check

- - Check the original part code is SK760101 where marked on the component or parts diagram

- - Check your shower is one of the Bristan mini valve models listed below

- - Check whether you need the green 7 L/min regulator or the yellow 5 L/min alternative

Confirmed Compatible Models

- - Bristan AE SHXAR C Acute Thermostatic Exposed Mini Valve Shower

- - Bristan CAP2 SHXAR C Capri Thermostatic Exposed Mini Valve Shower

- - Bristan SOQ2 SHXAR C Sonique Exposed Mini Valve Shower

- - Bristan AE2 SHXAR C Acute2 Thermostatic Exposed Shower Valve with Riser Kit Chrome

- - Bristan CAP3 SHXAR C Capri 3 Exposed Mini Valve Mixer Shower Chrome

- - Bristan NZA SHXAR C Onza Exposed Mini Mixer Shower Valve Chrome

- - Bristan NZA SHXAR BLK Onza Exposed Mini Mixer Shower Valve Black

- - Bristan SOQ3 SHCAR C Sonique 3 Concealed Mini Mixer Shower Chrome

- - Bristan SOQ3 SHXAR C Sonique 3 Exposed Mini Valve Mixer Shower Chrome

Related Spares You May Need

- - Bristan SK760090 Spare Yellow Flow Limiter 5l/m

- - Bristan SK780621 Filter (Ts6/800)

- - Sirrus SK970010 1/2 Inch Non-Return Valve (NRV)

- - Bristan SK100050 Evo Chrome Riser Rail dia 22mm length 660mm

- - Bristan SK100052 Evo Hose Retainer 22mm Diameter Chrome - (DEM 1 PA0093-01)

- - Bristan SK100053 Riser Bracket & Fixing Kit

- - Bristan SK100054 Spare Chrome Slider Bracket For EVO Kits

- - Sirrus SK1500-3 Thermostat and Piston (SK1500/3)

- - Sirrus SK971006 Colonial Cartridge WITH Wax Thermostat and Piston by Gummers / Bristan

- - Bristan SKD276-006CP Mini Valve Back Plate

- - Bristan SKD276-048 Mini Valve Exposed Elbow Support

- - Bristan SKD276-049CP Mini Valve Long Elbows

- - Bristan SKD276-050CP Mini Valve Short Elbows

- - 150mm Universal Shower Hose - NXT734

- - Bristan SK560604 No.8X1.5 Inch CSunk Woodscrew With Wall Plugs (x4)

- - Bristan SKD276-045CP Acute Mini Valve Flow Handle Chrome

- - Bristan SK1200-4CAPCP Capri Flow Handle Chrome

- - Bristan SK1200-4SQCP Sonique Valve Flow Handle

- - SK1200-1 Seal Kit for Sirrus Bristan and Gummers 1200 Series Thermostatic Cartridges used in Mini Sequential Valves

- - Bristan GRUB CP A4 M5X8 M5 x 8 CONE POINT A4 SS GRUB SCREW
