Franke FilterFlow Corinthian Valve Set 960X1959X2FFCOR Compatible Cartridge Spare

Summary

Franke FilterFlow Corinthian Valve Set 960X1959X2FFCOR Compatible Cartridge Spare

Franke FilterFlow Corinthian Valve Set 960X1959X2FFCOR

The Franke FilterFlow Corinthian valve set 960X1959X2FFCOR is a complete set of internal components for the Corinthian series of Franke FilterFlow shower valves. It includes the valves and cartridges required to control water flow and temperature for a Corinthian mixer valve assembly, restoring correct performance where worn parts have led to leaks, uneven flow, or temperature drift.

Function

This valve set combines the flow and control cartridges, seals, and internal mechanisms that manage hot and cold water flow through the mixer body. Each cartridge and valve in the set is designed to regulate water delivery smoothly, shut off reliably when turned off, and maintain consistent performance over repeated use.

Confirmed Compatible Models

This valve set is specified for Franke FilterFlow Corinthian series shower and bath shower mixer valves that originally use the FilterFlow design and parts numbering scheme. It is intended for valves marked or documented as compatible with 960X1959X2FFCOR in the Corinthian range.

Installation Notes

Before installing, isolate the hot and cold water supplies and remove the decorative trim, handles, and faceplate. Extract the old cartridges and valves from the mixer body, retaining internal clips or screws where applicable. Install each new valve and cartridge from the set, ensuring correct alignment with the inlet ports and handle splines. After reassembly, test the mixer at low pressure first, then normal supply to confirm correct shut-off and smooth flow control.

When Replacement Is Recommended

Replace this valve set if the shower or tap drips from the shower head or spout when turned off, if temperature control becomes unstable, if flow is uneven between hot and cold, or if handle operation feels stiff or inconsistent. A complete valve set replacement restores reliable water flow and accurate control without replacing the entire external trim or shower unit body.
