Ceramic Disc Cartridge - 1/2" BSP, 1/4 Turn Anti-Clockwise Open - 41mm Height, 36 Spline
Part number: 8AS655
Only 1 left in stock.
Price: £29.00
Sale: £19.83
You save: £9.17 (32%)
Price includes UK VAT (Region: UK▼)
In stock
Is this the right part?
Send a photo of your item and we'll help confirm it.
Product description
Summary
Ceramic Disc Cartridge - 1/2" BSP, 1/4 Turn Anti-Clockwise Open - 41mm Height, 36 Spline
Cartridge Measurements:
| Total Length (including bottom seal) | 41mm |
|---|---|
| Spindle Length | Diameter at Widest Point: 24mm |
| Top Spline Diameter | 9.8mm |
| Top Spline Teeth / Notches | 36 |
| Lower Thread Diameter | 27.8mm |
| Barrel Diameter Below Lower Thread | 23.8mm |
| Bottom Seal Colour | Blue |
| Close Direction | Anti-Clockwise Open (Clockwise Close) |
| Turn | Quarter Turn (1/4 Turn) 90° |
