Blanco Opera Hot Tap Valve Insert - 1/2", 20 Spline, 1/4 Turn - Compatible Cartridge
Send a photo of your item and we'll help confirm it.
Summary
Blanco Opera Hot Tap Valve Insert - 1/2", 20 Spline, 1/4 Turn - Compatible Cartridge
Measurements and Other Information: Blanco Opera Tap Cartridge
Measurements:
| Total length | 50mm (5cm) |
|---|---|
| Diameter at widest part | 23.8 |
| Spline diameter | 7.65mm |
| Number of splines | 20 |
Other information:
| Bottom seal colour | Red |
|---|---|
| Close direction | Anti-clockwise close (Clockwise open) |
| Original part number | 002520 |
The second photo above contains the measurement diagram of the Blanco Opera tap spare. Please check it against the cartridge you need to replace.
BL-OP92 is the Blanco Opera tap cartridge cold insert compatible spare. Please visit the page for the FAQs.
Tap Repair Guide: Blanco Opera Tap Cartridge Replacement
Isolate the water supply to the kitchen tap before starting the repair. Plug the drain to prevent small parts from falling in.
1. Remove the handle’s circular indice to access the screw under it.
2. Loosen the screw to remove the complete handle.
3. Grip a spanner on the nut of the cartridge and turn it anti-clockwise to remove.
4. Grease the replacement Blanco Opera tap spare cartridge with plumbing grease and insert it in the tap seat.
5. Use the spanner to secure and tighten the threads of the cartridge.
6. Restore the handle, screw, and indice.
