Blanco Cleo BM6100/02TB-CR Hot Tap Cartridge 1/2", 28 Spline - Cleo_BM6100/02 Compatible Cartridge
Send a photo of your item and we'll help confirm it.
Summary
Blanco Cleo BM6100/02TB-CR Hot Tap Cartridge 1/2", 28 Spline - Cleo_BM6100/02 Compatible Cartridge
Measurements of the Blanco Cleo spare cartridge compatible hot valve insert:
| Total length | 53.8mm (5.38cm) |
|---|---|
| Diameter at widest point | 23.8mm (2.38cm) |
| Cartridge nut height | 6.2mm (0.62cm) |
| Spline count | 28 |
| Bottom seal colour | Red |
| Close direction | Anticlockwise close |
| Open direction | Clockwise open |
Please check out the second photo for an illustration of these measurements.
The cold cartridge for the Blanco Cleo tap is also available.
Installing the Blanco Cleo Spare Cartridge
1. Detach the screw cap found under the left side handle to access the hot valve cartridge.
2. Undo the fixing screw and pull the handle out.
3. Remove the cartridge by gripping a spanner on the cartridge nut and turning it anticlockwise.
4. Coat the O-rings of the new Blanco Cleo spare hot valve insert.
5. Insert the cartridge in the tap and tighten.
6. Return the handle, fixing screw, and screw cap.
This Blanco Cleo compatible spare is also compatible with other taps.
