Abode Astbury AT3000 Monobloc Hot Tap Cartridge
Send a photo of your item and we'll help confirm it.
Summary
Abode Astbury AT3000 Monobloc Hot Tap Cartridge
This Abode AT3000XH hot tap cartridge is the hot-side ceramic disc cartridge for the Abode Astbury AT3000 Monobloc kitchen mixer tap. It is used to restore controlled hot water operation where the original hot valve has become stiff, worn, leaking or no longer shuts off correctly.
The Astbury AT3000 Monobloc uses quarter-turn ceramic disc control valves for precise flow control. This hot cartridge should be matched against the original cartridge, handle side and opening direction before ordering, especially if the tap has previously been repaired with non-original parts.
Technical Details
| Part Number | AT3000XH |
|---|---|
| Tap range | Abode Astbury Monobloc |
| Tap model | AT3000 |
| Cartridge position | Hot side |
| Valve type used in the tap | Ceramic disc QT |
| Tap operation | Quarter-turn handle action |
| AT3000 tap finish | Chrome |
| AT3000 tap construction | Low lead brass |
| Overall tap height | 370mm |
| Exit reach | 229mm |
| Exit height | 239mm |
| Base diameter | 60mm |
| Recommended tap hole diameter | 35mm |
| Maximum surface depth | 50mm |
| Spout aerator size | M20 |
| Tail pipe inlet / outlet size | M10 / 1/2 inch BSP male |
| Inlet pipe type / length | Flexible stainless braided hose / 480mm |
| Minimum / maximum water pressure | 0.40 / 5.5 bar |
| Recommended / maximum water temperature | 46 C / 70 C |
- Single flow tap with check valves integral to the hot and cold inlets
Confirmed Tap Model
Common Fault Symptoms
- Water dripping from the spout when the hot side is turned off
- Hot handle difficult to turn or not stopping cleanly at the closed position
- Poor shut-off caused by worn ceramic discs inside the hot cartridge
Before Ordering Check
Remove the existing hot cartridge and compare it with the image and Part Number AT3000XH before ordering. Check the handle side, spline engagement, cartridge body and opening direction, as hot and cold cartridges are usually handed and should not be swapped.
