LX JA35 Pump 0.35 HP | Hot Tub | Spa | Whirlpool Bath | Water Circulation Pump | 220V/50Hz | 1.6 Amp
LX JA35 Pump 0.35 HP | Hot Tub | Spa | Whirlpool Bath | Water Circulation Pump | 220V/50Hz | 1.6 AmpLX JA35 Pump 0.35 HP | Hot Tub | Spa | Whirlpool Bath | Water Circulation Pump | 220V/50Hz | 1.6 AmpLX JA35 Pump 0.35 HP | Hot Tub | Spa | Whirlpool Bath | Water Circulation Pump | 220V/50Hz | 1.6 AmpLX JA35 Pump 0.35 HP | Hot Tub | Spa | Whirlpool Bath | Water Circulation Pump | 220V/50Hz | 1.6 AmpLX JA35 Pump 0.35 HP | Hot Tub | Spa | Whirlpool Bath | Water Circulation Pump | 220V/50Hz | 1.6 Amp

LX JA35 Pump 0.35 HP - 220V/50Hz - 1.6 Amps

Part Number: LX-JA35-PUMP

SALE: £88.83

You save: £258.81 (74%)
Price includes VAT
Quantity:
ADD TO BASKET
2 Day Availability
Wrong Item? Click to see More
UK Lowest Price Guaranteed
Product description

SUMMARY

Manufacturer Model:JA35
Qmax Litres/Min150
Hmax (m):7.5
Voltage / Hertz:220V - 240V / 50Hz
Power (KW):0.25
Horsepower (HP):0.35
Ampage:1.6
Curves:N/A
Speed (Revolutions / Minute:N/A
Power (Watts):250
Heater Power (Watts):N/A
Maximum Pressure (Mpa):N/A
Maximum Pressure:N/A
Air Volume (m3/min):N/A
Noise Level dB (A):N/A
Jets Quantity (pieces):N/A
Recommended Water Depth (metres):N/A
Water Volume Heating Capacity (Gallons):N/A
Water Volume Heating Capacity (Litres):N/A
Fitting Size (mm):48.5mm or 50mm
Weight (Kg):5.1
Length (mm):350
Width (mm):175
Height (Kg):250
Power Cable Length:1.5 Metres
Pump Type:Water Circulation Pump
Brands Used On:
Will ship to:Worldwide
Suitable For:Hot Tubs (i.e. Jacuzzi) , Whirlpool Baths, Small Swimming Pools
Certification:CE, TUV
Water Protection Grade:IP55
Thermal Protector:TI.USA
Important Information:N/A
Other Information:Please contact us for more information about 230V / 60Hz, 110V / 60Hz models, 110V / 50Hz before ordering.
LX JA35 Pump 0.35 HP | Hot Tub | Spa | Whirlpool Bath | Water Circulation Pump | 220V/50Hz | 1.6 Amps

Brand: LX
Product: JA35 0.35 HP Water Circulation Pump
Maximum Water Flow: 150 Liters per Minute
Capacitor: 7 µF
Intended for: Hot Tub, Whirlpool Bath, and Spa Pools
Certification: TUV Certified and CE Certified
ProtectionL IPX5


The LX JA35 is a 0.35 horsepower single-phase (1 speed) water circulation pump. It is suitable for Chinese hot tubs, spa systems, and whirlpool baths. This type of pump can also fit tubs and spa brands from Europe and America.

LX JA35 has a top centre discharge. The pump will automatically self-drain after use. This water pump can be a suitable replacement for the LX TDA35.

This water circulation pump has an aluminum motor chassis. It has thermal protection that prevents the pump from overheating. The upper turbine of this centrifugal pump is reinforced engineered plastic making it a durable replacement pump for hot tubs, baths, and hydrotherapy spas.

For spas without an electronic control box, a pneumatic button can be connected to the LX JA35. It comes with a 1.5-metre power cable.


Need a more powerful LX hot tub pump?
We have a whole range of LX JA water circulation pumps in stock:
- LX JA50
- LX JA75
- LX JA120
- LX JA200


Choosing the Right Replacement Water Pump
It is necessary to check the label found on your old water pump and compare it with the specifications of the LX JA35 in the table above. You can also send us a message or check with your electrician.

Hydro-massages and bubbly waters are made possible with a water circulation pump. The machine discharges water through hot tub jets and circulates it throughout the tub. The proper voltage, horsepower, and frame size should be considered when searching for a replacement pump.

Voltage: A water pump can be 110-120 volts or 220-240 volts. The standard voltage of UK plugs is 230V/50 Hz. This LX JA35 fits that voltage/hertz specification. Should you need to modify it, please contact us.

Horsepower: Water pumps are available in horsepower as low as 0.35 (like this water pump) up to 5HP. Using a pump that is too powerful can damage the plumbing system.

Frame size: Water pumps are either a 48 frame or a 56 frame. Having the right frame size will ensure the water pump you will buy will fit into the bolts of your hot tub or spa system.


What is a Centrifugal Pump?
Centrifugal pumps move water through hydrodynamic energy. Water entering the impeller is accelerated, pushed towards the casing, and exits to a tub. The high flow rate of the pumps making it ideal for tubs and hydro-massage spa systems.
