Bristan 83T28174 Shower Bath Diverter for Jute BSM Valves
Send a photo of your item and we'll help confirm it.
Summary
The Bristan 83T28174 is a screw-in shower bath diverter mechanism for selected Bristan Jute bath shower mixer valves. It is the internal diverter spare used with the diverter knob to route water between the bath outlet and shower handset on supported Jute BSM and Jute PBSM assemblies.
The diverter is used where the bath shower mixer no longer changes outlet correctly, the diverter action is sticking, or water is escaping from the non-selected outlet. Check the original diverter and valve model before ordering, as this part is for the listed Bristan Jute bath shower mixer assemblies and is not a universal diverter.
Technical Details
| Part Number | 83T28174 |
|---|---|
| Part type | shower bath diverter mechanism |
| Fitting type | screw-in diverter |
| Total height | 62.4mm |
| Thread diameter | 26.7mm |
| Bottom o-ring diameter | 20mm |
| Middle o-ring diameter | 25mm |
| Top o-ring diameter | 29mm |
Confirmed Compatible Models
- Bristan JU BSM C Jute Bath Shower Mixer Spare Parts
- Bristan JU BSM C Jute Bath Shower Mixer Tap - 27/11/2014 - Spare Parts
- Bristan JU BSM E6 C Jute Bath Shower Mixer - 6 Litre Flow Limit Spare Parts
- Bristan JU BSM E8 C Jute Bath Shower Mixer - 8 Litre Flow Limit Spare Parts
- Bristan JU PBSM C Jute Pillar Bath Shower Mixer Spare Parts
Before Ordering
- Confirm the valve is a Bristan Jute bath shower mixer or Jute pillar bath shower mixer listed above.
- Compare the removed diverter with the 83T28174 height, thread diameter and o-ring positions.
- If the tap drips from the spout when fully turned off, also check the hot and cold ceramic tap cartridges because shut-off faults are normally controlled by the flow cartridges rather than the diverter knob.
Related Spares You May Need
- Bristan 206R30012CP-FEU09 Wall Bracket for Bath Shower Mixer Chrome
- Bristan 80D28174 Diverter Knob Chrome for JU BSM C
- Bristan 80N81050 Chrome Cap for Handle
- Bristan 81P20P52 Plastic Hexagonal 8x24 Spline Adaptor
- Bristan 8CM5X7 M5 x 7mm Grub Screw
- Bristan BLH85 3/4" Gold Metal Backnuts with Washers
- Bristan CAP ANT BSM M28 3 Piece Flow Straightener Chrome
- Bristan K22174A Cold Side 3/4" Cartridge. 3/4 x 24 splines x 52mm
- Bristan K22174B Hot Side 3/4" Cartridge. 3/4 x 24 splines x 52mm
- Bristan N12 Gasket Washer for ALTCNBSM
- Bristan P20P52 Pair of Handles for JU BSM Chrome (KE)
- Bristan WB 06630C Wall Bracket for Handset
