Vola 090V-16 Basin Swivel Spout - Chrome
Send a photo of your item and we'll help confirm it.
Summary
The Vola 090V-16 is a chrome basin swivel spout used as the outlet section in VOLA modular basin tap and mixer arrangements. This is the spout only and should not be ordered as a complete tap mixer, cartridge, handle or valve assembly.
The 090V swivel spout is used with a separate control unit or mixer body. It provides the rotating outlet for the basin tap and is intended for installations where the existing VOLA spout is damaged, worn, marked, restricted or being replaced during service work.
Technical Details
| Brand | Vola |
|---|---|
| Part code | 090V-16 |
| Part type | basin swivel spout |
| Finish | chrome 16 |
| Height | 355 mm |
| Projection | 145 mm |
| Spout hole cut-out | 22 mm |
| Escutcheon diameter | 40 mm |
| Pipe diameter | 19 mm |
| Connection size | 1/2 inch BSP male |
| Standard flow regulator reference | 9.0 L/min |
| Water activation | by separate control unit |
| Waste fitting | not included |
Before Ordering Check
Check the existing VOLA spout code, finish and installation layout before ordering. Do not select this part from diameter or thread size alone, as the 090V-16 is a specific VOLA basin swivel spout rather than a universal outlet.
Confirmed VOLA Models Using This Spout
VOLA 090V is the swivel spout used in 590V, 590VL, HV10 and HV10L assemblies. The -16 suffix identifies the chrome finish for the 090V-16 spout.
- Vola One-Handle Mixer with Ceramic Disc Technology for Table 590V Spare Parts
- VOLA 590VL one-handle mixer with long lever for table mounting 500 with swivel spout 090V
- VOLA HV10 three-hole mixer combination with swivel spout 090V
- VOLA HV10L three-hole mixer combination with long lever and swivel spout 090V
Related Spares You May Need
- Vola L-Holder for Aerator 9.0 L/Min. Chrome 16 (VR17L9K-16)
- 28mm Lever Cartridge for Vola VR277K - VR269 Fixing Nut NOT Included (Hastings) - Compatible Spare
- 28mm Lever Cartridge for Vola VR277 Mixer Taps (Hastings) - Compatible Spare
The VR17L9K-16 aerator holder is a direct spout-related spare for the 090V assembly. The VR277K and VR277 cartridges are listed as related system-level service spares through the verified VOLA 590V mixer spare parts page and are not subcomponents of the 090V-16 spout body.
