Grohe 2337700E Eurosmart Cosmopolitan Single-Lever Basin Mixer (1/2 Inch) S-Size Tap Spare Parts
Send a photo of your item and we'll help confirm it.
Summary
Spares for Grohe 2337700E Eurosmart Cosmopolitan Single-Lever Basin Mixer 1/2 Inch S-Size
The Grohe 2337700E Eurosmart Cosmopolitan is a chrome S-Size single-lever basin mixer with a fixed spout, cold-start ceramic control and a mechanically operated 1 1/4-inch pop-up waste. This page covers spare parts used to service the tap and its waste-control mechanism.
The 35 mm cartridge regulates water flow and temperature, while the central lever position supplies cold water to reduce unnecessary hot-water use. Service may be required if the spout drips when the tap is closed, the lever becomes stiff, the outlet stream deteriorates or the pop-up waste no longer opens and closes correctly.
Technical Details
| Brand | GROHE |
|---|---|
| Range | Eurosmart Cosmopolitan. |
| Category | Basin mixer. |
| Product code | 2337700E. |
| Installation | Single-hole deck-mounted monobloc installation. |
| Control | Metal lever with GROHE SilkMove ES 35 mm ceramic cartridge. |
| Cartridge code | 46863000. |
| Finish | Chrome. |
| Maximum flow rate | 5 litres per minute at 3 bar. |
| Tap height with the lever closed | 148 mm. |
| Spout projection | 92 mm. |
| Outlet height | 78 mm. |
| Required tap-hole diameter | 34 mm. |
| Maximum mounting-surface thickness | 30 mm. |
| Flexible supply connections | G3/8. |
| Pop-up waste connection | G1 1/4. |
| Production records | October 2012 to August 2017 and August 2017 onwards. |
Before You Order Check
Confirm the mixer model is 2337700E using the original paperwork or model identification, then compare the required component code and shape with the removed part. The specified 35 mm cartridge for this mixer is 46863000; do not select 46374000 solely because it is used in similar GROHE basin mixers.
GROHE 46460000 Screw Coupling Cartridge Headnut for Single-Lever MixersGROHE 46460000 is a screw coupling and cartridge-retaining headnut used around the single-lever cartridge assembly in specified GROHE basin, bidet, bath, shower, kitchen, GROHE Blue and GROHE Red mixers. It is...
GROHE 19332000 34mm and 32mm Socket Box Spanner for Tap and Shower CartridgesGROHE 19332000 is a double-ended tubular socket box spanner for servicing selected GROHE tap cartridges and thermostatic shower mixer assemblies. Its two differently sized hexagonal ends are used for the...
Grohe 07341000 350mm Horizontal Rod for PUW WasteThe Grohe 07341000 is a 350mm horizontal operating rod used in PUW waste control systems. It connects the tap mechanism to the basin waste linkage.FunctionThe rod enables mechanical operation of the waste plug. Incorrect length or ...
