Heritage Bathrooms TDCG00 Tap Cartridges (Pair) - Gold Finish
Send a photo of your item and we'll help confirm it.
Summary
Heritage Bathrooms TDCG00 Tap Cartridges (Pair). This comes as a pair of two cold cartridges as the hot cartridge is discontinued. You can use the cold as a replacement for the hot, it will just mean that the tap will turn on in the opposite direction.
The Heritage Bathrooms TDCG00 7ET4T4 is a pair of gold quarter-turn ceramic disc tap cartridges for the Heritage TDCG00 Dawlish Bathroom Basin Pillar Taps in Vintage Gold.
This pair is supplied as two cold cartridges because the original hot cartridge is discontinued. The cold cartridge can be used on the hot side, but the hot tap will turn on in the opposite direction after fitting.
These cartridges restore handle control and shut-off at the basin tap. Common signs that the tap cartridge may need replacing include water dripping from the spout when the tap is turned off, poor shut-off, a stiff handle or a handle that no longer controls the water flow correctly.
Technical Details
| Part type | pair of quarter-turn ceramic disc tap cartridges |
|---|---|
| Finish | gold |
| Total length including bottom seal | 81.8mm |
| Lower screw thread diameter | 20.5mm |
| Upper shroud screw thread diameter | 15.8mm |
| Spindle length including splines | 41mm |
| Tap application | Heritage Dawlish basin pillar taps with quarter-turn ceramic disc valves |
Confirmed Used In
Before Ordering
- Check the existing cartridge length, lower screw thread diameter, upper shroud thread diameter and spindle length before ordering.
- Check whether the hot side currently turns in the original direction, as fitting a cold cartridge on the hot side will reverse the opening direction.
- Isolate the water supply before removing the handle, shroud and cartridge from the tap body.
