Vado Astra AST-143/​H/​CD-3/​4-C/​P Wall Mounted Concealed Stop Ceramic Disc Valve Hot

SUMMARY

Vado AST-143/H/CD-3/4-C/P is a 3/4 inch wall-mounted concealed manual stop valve from the Astra range, supplied in chrome with a contract handle and hot indice.

This single stop valve controls on and off water flow to the outlet. It uses a ceramic disc shut-off mechanism for quarter-turn operation and is suitable where a concealed manual hot-side stop valve is required. Common signs of wear include stiff operation, difficulty shutting off fully or continued flow when the valve is turned off.

Technical Details

- - Part Number: AST-143/H/CD-3/4-C/P

- - Product type: single wall-mounted concealed stop valve assembly

- - Range: Astra

- - Size: 3/4 inch

- - Handle style: contract handle

- - Indice: hot

- - Finish: chrome

- - Feature: easy clean

- - Minimum operating pressure: 0.3 bar

- - Operation: quarter-turn ceramic disc shut-off

Before Ordering

Check the full code AST-143/H/CD-3/4-C/P on the existing valve or specification, confirm that you need the 3/4 inch hot version, and note that this listing is for the concealed stop valve assembly rather than a standalone internal cartridge.

Installation Notes

Isolate the water supply before removal, and confirm the hot-side orientation and connection size before fitting the replacement valve.
