INTA NC300CP Pushtap Non-Concussive Self Timed Tap Cartridge with Gasket

SUMMARY

INTA NC300CP Pushtap Non-Concussive Self Timed Tap Cartridge with Gasket - 15 sec. @ 1 bar

The INTA NC300CP is a Pushtap non-concussive self timed tap cartridge supplied with gasket for selected Inta timed-flow basin and wall-mounted taps.

This cartridge controls the push-button timed flow and self-closing action of the tap. It is specified as 15 seconds at 1 bar, making it suitable for Inta Pushtap applications where controlled water run time is required.

Technical Details

- - Part code: NC300CP

- - Di Vapor Part Number: IN-NC300CP

- - Timed flow: 15 sec. @ 1 bar

- - Approximate overall length: 78mm

- - Approximate length of white plastic section: 19mm

- - Approximate widest point of white plastic section: 24mm

- - Approximate external thread diameter: 25.5mm

Used In

- - Inta NC180CP Basin Mounted Mixer Tap with Temperature Control Spare Parts

- - Inta NC160CP Non Concussive Basin Mounted Standard Tap (Pairs) Spare Parts

- - NC160CP(S) Basin Mounted Non-Concussive Taps

- - NC165CP 3 Second Basin Mounted Non-Concussive Taps

- - Inta NC165CP(S) Basin Mounted Non Concussive Tap 3 Sec (Single) Spare Parts

- - Inta NC170CP Non Concussive Wall Mounted Tap (Pairs) Spare Parts

- - Inta NC160CPS5 Non-Concussive Basin-Mounted Standard Tap (Single) 5 Litre Per Min Spare Parts

Before You Order Check

Check the existing tap model, cartridge code, timed-flow requirement and thread size before ordering. This cartridge is for the listed Inta non-concussive timed tap applications and should not be selected from measurements alone.

Common Fault Symptoms

- - Symptom: tap will not shut off correctly after being pressed. Likely Cause: worn or sticking timed cartridge. Solution: replace the NC300CP cartridge and gasket.

- - Symptom: water flow stops too quickly or runs for too long. Likely Cause: failed timed-flow cartridge or incorrect operating pressure. Solution: confirm system pressure and replace the cartridge if the tap assembly is correct.

- - Symptom: water leaks around the push tap cartridge area. Likely Cause: worn cartridge gasket or damaged seal area. Solution: inspect the seating area and replace the cartridge with its gasket where required.
