Hansgrohe 13954000 Chrome Angle Valve with Compression Fitting

SUMMARY

Hansgrohe 13954000 Chrome Angle Valve DN15 with 10 mm Compression Fitting and Cover

The Hansgrohe 13954000 is a chrome DN15 angle isolation valve for a wall-fed washbasin installation. It provides a controlled connection between the wall supply and a 10 mm tube and is supplied with a matching decorative cover.

This angle valve is for use with the 52120000 Bottle trap Flowstar with angle valves. The complete 52120000 installation uses two angle valves and two covers for the paired water supplies.

Technical Details

- - Manufacturer: Hansgrohe.

- - Part code: 13954000.

- - Valve designation: DN15.

- - Finish: Chrome.

- - Inlet connection: G 1/2.

- - Outlet connection: G 3/8.

- - Compression connection: For 10 mm tube.

- - Connection thread: Self-sealing.

- - Supplied components: Angle valve and decorative cover.

- - Valve-body length shown in the manufacturer drawing: 80 mm.

- - Height to the compression outlet shown in the manufacturer drawing: 45 mm.

- - Decorative-cover length shown in the manufacturer drawing: 85 mm.

Confirmed Application

- - Hansgrohe 52120000 Bottle trap Flowstar with angle valves - production after 10/01.

Before Ordering

Check the code marked on the existing valve and compare the G 1/2 inlet, G 3/8 outlet, 10 mm compression connection and cover dimensions before ordering. Hansgrohe 13954800 is the stainless steel optic finish variant and should not be ordered when the chrome 13954000 version is required.
