Grohe 24045000 Eurosmart Cosmopolitan Single-Lever Mixer with 2-Way Diverter Shower Spare Parts

SUMMARY

Shower Spares for Grohe 24045000 Eurosmart Cosmopolitan Single-Lever Mixer with 2-Way Diverter

- Grohe Rapido Smartbox (35 600)

- Grohe SilkMove 46mm Ceramic Cartridge

- Automatic 2-Way Diverter

Grohe 24045000 is the chrome final-installation trim set for a concealed GROHE Eurosmart Cosmopolitan single-lever bath shower mixer with an automatic 2-way diverter. It combines the operating lever, diverter control and circular metal escutcheon for a GROHE Rapido SmartBox installation. The concealed rough-in box is not included.

The single lever controls water temperature and flow, while the automatic diverter selects between two bath or shower outlets. It can be used where two functions, such as a bath spout and handset or a fixed shower head and handset, are operated from the same concealed mixer.

Technical Details

- - Range: GROHE Eurosmart Cosmopolitan

- - Category: Bath shower mixer

- - Product code: 24045000

- - Product type: concealed single-lever mixer trim set with automatic 2-way diverter

- - Finish: chrome with GROHE LongLife finish

- - Mixing cartridge: GROHE SilkMove 46mm ceramic cartridge

- - Escutcheon: metal FastFixation escutcheon with covered shaft sealing and covered fixing

- - Escutcheon diameter: 158mm

- - Escutcheon depth: 10mm

- - Faceplate adjustment: up to 6 degrees after installation

- - Outlet flow rate: outlet B 27 l/min and outlet C 27 l/min

- - Installation system: GROHE Rapido SmartBox 35 600 or 35 604

- - Rough-in set: not included

Confirmed Installation Systems

- - Grohe 35600000 Rapido Smartbox Universal Rough-In Box 1/2 Spare Parts

- - GROHE Rapido SmartBox 35604000

Fault Symptoms

- - Water continuing to drip from the shower head or bath spout after the mixer has been turned off may indicate wear in the ceramic mixing cartridge or its seals.

- - Water failing to switch cleanly between the two outlets may indicate wear or obstruction within the diverter components.

Before You Order Check

Before you order check that the mixer code is 24045000, that the required visible finish is chrome and that the concealed installation uses the correct GROHE Rapido SmartBox. Identify whether the fault is within the trim, ceramic cartridge, diverter or concealed rough-in before selecting a spare.
