Grohe 24044000 Eurosmart Cosmopolitan Single-Lever Shower Mixer Spare Parts

SUMMARY

Spares for Grohe 24044000 Eurosmart Cosmopolitan Single-Lever Shower Mixer

- Set for Final Installation for Grohe Rapido SmartBox (35 600)

- Grohe SilkMove 46mm Ceramic Cartridge

The Grohe 24044000 Eurosmart Cosmopolitan is a concealed single-lever shower mixer. This chrome final-installation set is used with a Grohe Rapido SmartBox concealed rough-in body and uses a Grohe SilkMove 46mm ceramic cartridge to control mixed-water temperature and flow.

The operating trim includes a metal lever and metal escutcheon. The concealed Rapido SmartBox rough-in body is a separate installation component and should be identified before ordering parts.

Technical Details

- - Range: Grohe Eurosmart Cosmopolitan

- - Category: Shower mixer

- - Model code: 24044000

- - Installation type: concealed single-lever final-installation set

- - Finish: chrome

- - Cartridge: Grohe SilkMove 46mm ceramic cartridge 46048000

- - Escutcheon: metal FastFixation type with covered shaft sealing and covered fixing

- - Escutcheon adjustment: up to 6 degrees

- - Escutcheon diameter: 158mm

- - Escutcheon depth: 10mm

- - Overall vertical dimension shown on the Grohe technical drawing: 172mm

- - Maximum flow through outlet B or outlet C: 30 l/min

- - Recommended flow pressure: 1 to 5 bar

- - Maximum operating pressure: 10 bar

- - Maximum hot-water supply temperature: 70 degrees C

Confirmed Installation Systems

- - Grohe 35600000 Rapido Smartbox Universal Rough-In Box 1/2 Spare Parts

- - Grohe Rapido SmartBox 35604000

Before you order check

Confirm that the shower mixer is Grohe model 24044000 and check the concealed Rapido SmartBox installation before ordering. When replacing the cartridge compare the existing part with the 46048000 cartridge and check its condition before dismantling the valve.
