90 Degree Wall Mounted Shower Door Glass Hinge | Chrome Plated | Double Sided | Tapered Edges

SUMMARY

IMPORTANT Before ordering any custom glass, please ensure that your glazier is able to inspect the hinge in person. Any slight difference in the cutout before the glass is tempered will result in the glass needing to be re-cut. Di Vapor will not be responsible for any costs incurred with re-temper or re-cutting of glass. DO NOT order your glass before you have ordered the hinge(s) and have them to hand.

--------------

What's included
- The copper 90 degree glass hinge (please read description below for how the hinge works)
- Allen key
- 4 x wall fixing screws and 4 x wall plugs
- 2 x chrome finishing caps to cover the hinge's allen key bolts.
- Gasket paddings (which will come already inside the hinge)

The hinge is centred in the middle of the wall mounting plate. If you require the hinge to be offset, we have hinges in our range that are the same design but offset to one side. This hinge requires the glass to be cut out in the same shape as the technical diagram.

--------------

Useful Information Regarding this Glass Hinge

Hinge Weight: 365g (0.365kg)
Fixing Type: Wall mounted fixing.
Glass Thickness: 8 - 10mm
Glass Requirements: Glass cut out is required. Please see technical cut out diagram in photos section for detailed measurements.
Material: Chrome Plated Zinc Alloy
Finish: Polished chrome (mirror finish)
Weight Limit and Maximum Glass Panel Size: The maximum weight limit per hinge is 25kg. We recommend that this weight limit is adhered to and considered when deciding how many hinges are being used per panel. Typical usage for most panels and doors is 2 -3 hinges per side. The maximum width of the glass door should be no more than 700mm.
Uses: Any glass panel or door. This can be inside or outside the bathroom. Can be in living room or kitchen, the hinge looks great everywhere around the home or office.
Door Opening Function: This hinge will swing 180 degrees. That means that it will swing outwards 90 degrees and inwards 90 degrees. The hinge is a snap fixing which means that when it is opened it will automatically want to turn to a 90 degree position.
Design Style: Smoothed tapered edges

-- The hinge has been tested to open and close a shower door up to 100,000 times.
-- Designed to fit onto a glass panel as per the technical diagram.
-- Glass needs to be tempered safety glass.
