SPACW0009 Crosswater Hot Flow Cartridge for 322, 422 and KO340 Shower /​ Bath Valves

SUMMARY

Crosswater SPACW0009 Hot On/Off Flow Cartridge for 322, 422 and KO340 Bath and Shower Valves - Clockwise Open

Crosswater SPACW0009 is a hot-side on/off flow cartridge for selected Crosswater 322, 422 and KO340 bath and shower valve applications. It controls the hot-water supply within the fitting and opens when the handle is turned clockwise.

This is a flow-control cartridge, not a thermostatic temperature cartridge or an outlet diverter. A worn or damaged flow cartridge can cause stiff handle operation, unreliable shut-off or water continuing to drip from the bath spout or shower head after the control has been turned off.

Technical Details

- - Part number: SPACW0009

- - Part type: on/off flow cartridge

- - Control position: hot-water side

- - Opening direction: clockwise

- - Closing direction: anti-clockwise

- - Application references: selected Crosswater 322, 422 and KO340 bath and shower valves

Before Ordering

Check the complete tap or valve model and the original cartridge reference before ordering. The 322 and 422 references are not complete model codes and do not mean that this cartridge fits every Crosswater product with either number in its model code.

Compare the original cartridge's body shape, thread, spindle, handle connection, opening direction and sealing arrangement. Do not select the cartridge from appearance or a single measurement alone, and do not assume that a different Crosswater cartridge code is interchangeable with SPACW0009.

Installation Notes

Isolate the hot and cold water supplies before removing the existing cartridge. Follow the fitting manufacturer's servicing instructions, check the cartridge seating area for debris and test for leaks and correct shut-off after installation.

Related Spares You May Need

- - Crosswater SPACW0012 Cold Flow Cartridge for selected 322, 422 and KO340 Bath and Shower Valves - the corresponding cold-side part

Not sure this is the right cartridge? Use our part identification service for help.
