3kW Electric Water Heater Element | 220V / 230V for Steam Generators and Other Water Heating Devices

Part Number: ELHE02
Next Day Delivery
Dispatches tomorrow if ordered within 15 hrs 5 min
Price: £49.95
Price includes VAT
Quantity:
IN STOCK
Tick14 day money-back guaranteeTickEasy Returns if it doesn't fit

Part Details Delivery & Returns Payment & Security
Part Details

Summary

This is a universal 3KW water heating element which is often used in steam generators but is also used in the following equipment:
- Steam Generators for steam rooms and steam showers (and any other steam generator)
- Dryers
- Radiators
- Boilers
- Industrial machines
- Any water heating or water boiling where this element will fit.

Features
- Corrosion resistant
- Stainless steel
- U shaped coil at end (4 coils)

Technical information

Heating Element Type: Water Heater Element
Rated Voltage: AC 220V / 230V
Power: 3kW Kilowatt
Length of heating element (up to the fixing plate): 104mm / 10.4cm (4.1" inches)
Total Weight: 180g
Material: Stainless Steel (for coiled element) and Stainless steel fixing plate
Element Diameter: 6.6mm / 0.26" Inches
Total Length: 122mm (12.2cm) 4.82" Inches
Width of heating element coil at maximum point: 41mm (4.8cm) 1.63" inches
Width of fixing plate: 69.2mm / 6.9cm (2.73" Inches)
Height of fixing plate: 69.2mm / 6.9cm (2.73" Inches)
Number of heating element connections: 2
Number of fixing holes on fixing plate: 4

If you can't find the heating element or part which you're looking for or want to clarify you have the correct one, simply go to our Find a part page, and send us a photo of what you need with any measurements you have.
