Grohe 32488000 Minta Single-Lever Kitchen Tap Spare Parts
Send a photo of your item and we'll help confirm it.
Summary
Spares for Grohe 32488000 Minta Single-Lever Kitchen Tap
The Grohe 32488000 Minta is a single-lever kitchen tap with a high U-shaped swivel tubular spout and chrome finish. The single lever controls both water flow and temperature, while the selectable swivel range allows the spout movement to be configured for different sink layouts.
This Minta kitchen tap uses a 46 mm ceramic cartridge for flow and temperature control. Grohe spare parts available for servicing this model include the cartridge, outlet aerator and mounting assembly, allowing commonly worn components to be replaced without changing the complete tap.
Technical Details
| Brand | Grohe |
|---|---|
| Range | Minta |
| Category | Kitchen tap |
| Model code | 32488000 |
| Type | Single-lever sink mixer 1/2 inch |
| Finish | Chrome |
| Cartridge | 46 mm ceramic cartridge |
| Spout | High U-shaped swivel tubular spout |
| Selectable swivel range | 0 / 150 / 360 degrees |
| Overall tap height | 309 mm |
| Spout outlet height | 219 mm |
| Spout projection | 223 mm |
| Tap body diameter | 54 mm |
| Required mounting hole | 34 mm |
| Maximum deck thickness | 60 mm |
| Flexible hose connection | G3/8 |
| Maximum flow rate at 3 bar | 11.5 l/min |
| Minimum flow pressure | 0.5 bar |
| Recommended flow pressure | 1-5 bar |
| Maximum operating pressure | 10 bar |
| Maximum hot-water inlet temperature | 80 degrees C |
| Recommended hot-water temperature | 60 degrees C |
| EAN | 4005176289552 |
Before You Order Check
Before you order check that the tap code is 32488000 and compare the part being replaced with the existing component, particularly where the tap has previously been serviced or modified.
