Stuart Turner 46534 Showermate Universal 2.6 bar Single Shower Pump
Send a photo of your item and we'll help confirm it.
Summary
Showermate Universal Single pumps can be usedin pairs to pump hot and cold water supplies independently, or as asingle pump to boost a water supply as required. Suitable forboth positive and negative head applications.
Suitable for domestic use only, ShowermateUniversal pumps are suitable for installation into openvented hot and cold water systems.
Universal pumps do not require a gravity flowof water to start.
- Boost the water pressure in either the hot or cold supply
- Suitable for single or multiple (up to 4) outlets within abathroom subject to correct specification and pump sizing.
Technical Specification
| General | |
| Product code | 46534 |
| Guarantee | 3 years |
| WRAS approval | 1212078 |
| Features | |
| Pump type | Peripheral |
| Mechanical seal | EPDM / PTFE / Al. Oxide |
| Anti vibration feet | |
| Flexible hoses | 2 |
| Run on timer | 3 sec |
| Dry run protection | |
| Materials | |
| Pump body | Plastic |
| Impeller | Plastic |
| Performance | |
| Maximum head (closed valve) | 2.6 bar |
| Performance @ 9 l/min | 1.3 bar |
| Performance @ 18 l/min | 0.3 bar |
| Maximum flow | 18 l/min |
| Maximum static inlet pressure | 6 metres |
| Maximum static outlet pressure | 6 metres |
| Maximum working pressure* | 380 kPa (3.8 bar) |
| Maximum ambient air temperature | 40 °C |
| Min / Max water temperature** | Min 4 °C / Max 65 °C |
| Flow switch sensitivity (approx) | 0.8 l/min |
| Pressure vessel air pre-charge | 1.5 bar (21.75 psi) |
| Connections | |
| Pump connections | G ¾ male |
| Flexible hoses | |
| Connections | G ¾ female x 15 mm push-in 200 mm long Isolating valves on inlet hoses |
| Motor | |
| Type | Induction, auto-reset thermal trip |
| Duty rating | Continuous (S1) @ 9 l/min and above |
| Electrical | |
| Power supply/phase/frequency | 230 V a.c./ 1 / 50 Hz |
| Current (full load) | 1.2 Amps |
| Power consumption | 280 Watts |
| Fuse rating | 5 Amps |
| Power cable (pre-wired) | 1.5 metres |
| Physical | |
| Enclosure protection | IP22 |
| Length | 233 mm |
| Width | 139 mm |
| Height (excluding hoses) | 338 mm |
| Weight (including fittings) | 4.7 Kg |
* The maximum pressure that can be applied to the pump under anyinstallation conditions.
** A stored water temperature of 60 °C is considered sufficientto meet all normal requirements and will minimise deposition ofscale in hard water areas.
