|Mechanical seal||EPDM / PTFE / Al. Oxide|
|Anti vibration feet|
|Dry run protection|
|Maximum head (closed valve)||1.8 bar|
|Performance @ 9 l/min||1.5 bar|
|Performance @ 18 l/min||0.8 bar|
|Maximum flow||33 l/min|
|Maximum static inlet pressure||13 metres|
|Maximum working pressure*||380 kPa (3.8 bar)|
|Maximum ambient air temperature||40 °C|
|Min / Max water temperature**||Min 4 °C / Max 65 °C|
|Flow switch sensitivity (approx)||0.8 l/min|
|Pump connections||G ¾ male|
|Connections||G ¾ female x 15 mm push-in|
200 mm long
Isolating valves on inlet hoses
|Type||Induction, auto-reset thermal trip|
|Duty rating||Continuous (S1) @ 9 l/min and above***|
|Power supply/phase/frequency||230 V a.c./ 1 / 50 Hz|
|Current (full load)||1.8 Amps|
|Power consumption||405 Watts|
|Fuse rating||5 Amps|
|Power cable (pre-wired)||1.5 metres|
|Height (excluding hoses)||179 mm|
|Weight (including fittings)||4.7 Kg|
* The maximum pressure that can be applied to the pump under anyinstallation conditions.
** A stored water temperature of 60 °C is considered sufficientto meet all normal requirements and will minimise deposition ofscale in hard water areas.
*** Both heads pumping 4.5 l/min and above.
