Grohe 23322001 Eurosmart Single-Lever Basin Mixer (1/2 Inch) M-Size Spare Parts
Send a photo of your item and we'll help confirm it.
Summary
Spares for Grohe 23322001 Eurosmart M-Size Single-Lever Basin Mixer 1/2 Inch
GROHE 23322001 is an Eurosmart M-size single-lever basin mixer in chrome with a mechanical 1 1/4 inch pop-up waste. The monobloc mixer installs through a single tap hole and uses flexible hot and cold inlet connections.
The 28mm ceramic cartridge controls the water flow and temperature through the single lever. A rear lift-rod mechanism transfers movement from the mixer to the basin waste so the plug can be opened and closed from above the basin.
Technical Details
| Brand | GROHE |
|---|---|
| Range | Eurosmart |
| Category | Basin mixer |
| Product code | 23322001 |
| Manufacturer-formatted code | 23 322 001 |
| EAN | 4005176934506 |
| Mixer size | M-size |
| Installation | Single-hole monobloc |
| Finish | Chrome |
| Lever | Metal single lever |
| Cartridge | 28mm ceramic cartridge with GROHE SilkMove and an adjustable temperature limiter |
| Maximum flow rate | 5 litres per minute at 3 bar |
| Flexible inlet connections | G3/8 with 380mm hoses |
| Pop-up waste connection | 1 1/4 inch |
| Closed overall height | 169mm |
| Spout outlet height | 83mm |
| Spout projection | 110mm |
| Mixer base diameter | 48mm |
| Required tap-hole diameter | 34mm |
| Maximum mounting-surface thickness | 30mm |
Common Faults and Checks
- A worn cartridge can cause water to drip from the spout when the tap is turned off, stiff lever movement or reduced control of the water flow and temperature.
- A bent, worn or incorrectly adjusted pop-up waste rod can prevent the basin plug from opening or closing fully.
- Before ordering, confirm product code 23322001, compare the original cartridge and mounting arrangement, and measure the waste operating rod because the standard 180mm and optional 350mm rods are different lengths.
Installation Note
Isolate the hot and cold water supplies before dismantling the mixer. Compare each replacement part with the removed component, align and adjust the pop-up waste linkage for full travel, then flush the supplies and check the water and waste connections for leaks after reassembly.
