Grohe 23106001 Lineare Chrome Single-Lever Basin Mixer (1/2 Inch) S-Size Tap Spare Parts
Send a photo of your item and we'll help confirm it.
Summary
Spares for Grohe 23106001 Lineare Chrome Single-Lever Basin Mixer 1/2 Inch S-Size Tap
The Grohe 23106001 Lineare is a chrome S-Size single-lever basin mixer for single-hole deck mounting, with a fixed spout, smooth body and push-open basin waste. This spare parts page covers service components associated with the exact 23106001 basin mixer.
The metal lever controls the water flow and mixed-water temperature through a 28 mm ceramic cartridge with an integrated temperature limiter. The Grohe spare parts listed below allow the cartridge and basin waste to be serviced individually when wear causes dripping, poor lever control or leakage through the closed waste.
Technical Details
| Brand | Grohe |
|---|---|
| Range | Lineare |
| Category | Basin mixer |
| Product code | 23106001 |
| Product type | Single-lever basin mixer 1/2 Inch S-Size |
| Finish | Chrome |
| Installation | Single-hole deck-mounted installation |
| Body configuration | Smooth body |
| Lever | Metal single lever |
| Cartridge | GROHE SilkMove 28 mm ceramic cartridge with an integrated temperature limiter |
| Spout | Fixed spout |
| Outlet angle | 15 degrees |
| Outlet insert | GROHE SpeedClean mousseur |
| Maximum flow rate | 5 litres per minute at 3 bar |
| Mixer height above the mounting surface | 180 mm |
| Overall height with the lever raised | 213 mm |
| Spout outlet height | 120 mm |
| Spout projection | 128 mm |
| Mixer body diameter | 48 mm |
| Required mounting-hole diameter | 34 mm |
| Maximum mounting-surface thickness | 30 mm |
| Flexible hose length | 360 mm |
| Flexible hose connection | G3/8 |
| Installation system | GROHE FastFixation Plus |
| Waste | 1 1/4 Inch push-open basin waste set |
| Waste flange diameter | 63 mm |
| Waste clamping range | 32 mm to 45 mm |
| Waste outlet thread | G1 1/4 |
| EAN | 4005176409110 |
Service and Fault Checking
A persistently dripping basin mixer can indicate wear within the ceramic cartridge, while water passing through the basin waste when it is closed can indicate contamination or wear within the waste sealing components.
Before you order, confirm that the basin mixer is marked or documented as 23106001, because visually similar Lineare mixers can use different cartridges, handles, mounting parts and waste arrangements.
Isolate the hot and cold water supplies before dismantling the mixer. The lever fixing uses a 3 mm Allen key, while the cartridge retaining assembly is shown with a 27 mm spanner.
